TECHNICAL FEATURES
Available with various special sealing systems
Impeller hydraulically balanced to prevent axial thrusts against the seal, it achieves 80% efficiency.
Made of stainless steel AISI 304 for 3D SERIES and AISI 316 for 3D 65
Back pull-out design : it allows removal of the motor, the coupling, the cantilever
support and the impeller without compromising the housing of the pump body or removing the pipes.

LIQUID TEMPERATURE RANGE
from -10°C to + 90°C for the standard version
from -20°C to + 120°C for the special versions

MAXIMUM WORKING PRESSURE
10 bar
